Azure Firewall Tips: Target FQDN Wildcard

If I want to allow this URL of Azure Cognitive Service to access the Internet rhtough Azure Firewall, how many rules can I achieve this?

Azure Firewall FAQ

FAQ for Azure Firewall. A managed, cloud-based network security service that protects your Azure Virtual Network resources.

Microsoft Learnduongau

Actually, based on Azure Firewall FAQ, this Q&A is specifically explained. However, to ensure everyone has the same understanding of the explanation, I specifically used the nedpoint provided by Azure AI Foundry to conduct an experiment

https://pichuang.services.ai.azure.com

Azure Firewall Policy Capabilities

In Azure Firewall, the only place where wildcards can be used in the Application Rules within Azure Firewall. Network Rules do not support using wildcards to specify URLs.

Depending on the selected Azure Firewall SKU, we offer different capabilities, as shown in the figure below:

Due to the most common use of the Target FQDN mehod, the following explanation will focus solely on this as the primary example for reference.

Failed Output

Before rewriting the firewall policy, you need to first understand how common error messages are presented. Below are examples of encoutering as SSL_ERROR_SYSCALL and Azure Friewall denying access due to the absence of matching rules.

$ curl https://pichuang.services.ai.azure.com
curl: (35) OpenSSL SSL_connect: SSL_ERROR_SYSCALL in connection to www.azure.com:443

$ curl http://pichuang.services.ai.azure.com
Action: Deny. Reason: No rule matched. Proceeding with default action

Undestand of Wildcard in Application Rules

1. Asterisks work when placed on the left-most side.
2. Asterisks on the left-most side mean literally anything to the left matches, meaning multiple subdomains and/or potentially unwanted domain name variations are matched.
3. Traffic processed by application rules are always SNAT-ed. If you want to see the original source IP address in your logs for FQDN traffic, you can use network rules with the destination FQDN

TargetFQDN Rule Design

Let's count how many rules can allow the following URL to pas through the firewall

https://pichuang.services.ai.azure.com
